Polymer Testing

Moisture Analysis

Moisture analysis of plastics
Moisture analysis in the form of the HYDROTRACER HT3® Moisture Meter for Plastics from Aboni.

The water content of High-Tech plastic material has considerable effect on the quality of the finished product. Testing needs to be performed simply and accurately using a dedicated instrument.

The HYDROTRACER HT3® moisture analyser uses a modified Calcium Hydride method as described in ISO 15512:2019 “Plastics – Determination of water Content, method E.”

Aboni have been designing moisture analysis equipment for over 25 years. The HYDROTRACER HT3® has been painstakingly designed and developed to reliably measure the residual moisture content of pellets, powders or finished parts.

As the principle of operation is an absolute chemical method, no calibration is required to the respective test material.

Connected to a PC via USB cable, HYDROTRACER HT3® easy to use software guides the operator step-by-step through the moisture analysis measurement process and saves the results in a concise PDF report.

See HydroTracer HT3 in action here

Our partners

Moisture analysis
HYDROTRACER HT3® Moisture Analysis

Technical Data:

Measurement principle / test methods: Chemical reaction with calcium hydride according to DIN EN ISO 15512:2019

Sample weight / sample volume: From 0,1g / max. 130 cm3
Resolution: 0,01 mg / 1 ppm / 0,0001 % H2O
Measuring range: 0.20 to 25 mg /0.0001 to 5% H2O
Measuring temperatures: 50°C – 210°C in 1°C steps
Measuring time: Approx. 10 – 45 min. (depending on material)
Display: %, ppm, mg
Interfaces :USB
Power supply: 100 – 240 VAC /60Hz, Max 1000 W

Operating temperature:10 – 45 °C
Air humidity: 5 – 95 % rF
Dimensions: (W x H x D) / 29  × 18 × 26 cm / 6.4 kg

Moisture Analysis on the Move! Handy carry case to help transport your HydroTracer safely

HYDROTRACER HT3® is robust, compact and easily transportable – ideal for multiple uses, in many areas of the plastics production process, including:
• Moisture analysis of incoming granulates and raw materials
• To monitor and optimise the drying of granulates or powders
• To measure the moisture content of granulates in situ, during production
• To test a finished component, e.g. after conditioning
• To take laboratory measurements for quality control or product development purposes
• Moisture analysis perfect for anyone looking at the moisture content of plastics.

CALL US NOW on +44 (0) 1420 593680 to arrange your onsite Demo
